The booster kit comes in 2 boxes:

1. Thermo-shield + Ground insulation: 80x40x23, 14~ kg
2. Thermo-regulator: 30x40x13, 4.1 kg

The HomeBiogas system, in general, should be placed outdoors only in a place where it can get maximum sunlight) and on a stable floor free from any obstructions.

It is important to place your system close to a water source and to have a free space of 0.5meter (1.6 ft)  from each of the system’s sides to have easy access to the system. The stove can be placed up to 7m (22 ft) from the system.

You will need access to an electrical plug situated up to 6m(22 ft)  from the system.

The Booster Kit requires a surface area of minimum 2 x 3m (6.55 feet by 9.85 feet), and the height of the dome is 1.4m(4.6 feet).

You will need a surface area of minimum 2 x 3m (6.55 feet by 9.85 feet).
The height of the dome is 1.4m (4.6 feet).

The system will auto-regulate in any temperature to stay at an optimal temperature. We recommend using the Booster Kit when temperatures drop below 18°C/64.4°F on average (weekly). We do not recommend using the system if  the weekly average temperatures drop below 4°C/39.2°F.

No, the system does not use biogas for heating. The biogas is only used for cooking with the HomeBiogas stovetop. The heating is created with the submersible heater, which is specifically designed for HomeBiogas systems, and it has an energy-efficient self-regulating heating element and a thermostat with auto shutoff to maintain the optimal temperature at all times. Additionally, the heating is maintained via the greenhouse effect created by the thermo shield, which is trapping the sun’s heat, and the ground cover and insulation, which prevent heat loss through the ground.

The power consumption of the HomeBiogas Booster Kit varies depending on circumstances such as temperature and sunlight. The colder it gets, the more energy it will require.

The HomeBiogas Booster Kit is designed as a DIY product to be put together by two people in about two hours. Every HomeBiogas system comes with a very detailed manual that explains every step of the way.

–Thermo Regulator: Energy-efficient self-regulating heating cable, and a thermostat with auto shutoff connected to a control box to maintain the optimal temperature at all times.
–Thermo Shield: A protective barrier between your HomeBiogas and the environment.
–Ground Cover: PP woven sheet layer to help prevent plant growth around the system .
–Ground Insulation: An additional HDPE layer that prevents heat loss through the ground.

The ground insulation is made of high-density polyethylene (HDPE). It has geometry of cups to keep the system above the ground with air trapped to insulate the system.

Grass or dirt is preferred as we use spikes to hold down the thermo shield. If it’s cement, another type of spikes will need to be drilled into the ground.

The booster kit is not currently available for any systems other than the HomeBiogas 2 but may be released in the future, stay tuned!

The thermo regulator includes a thermostat with a temperature sensor that ensures the system doesn’t overheat.

The thermo regulator includes a thermostat that ensures the system doesn’t overheat.

The heat generated by the thermo regulator is dispersed throughout the 20-meter self-regulating heating cable, preventing it from causing damage to the system.

If the thermo regulator stops working, you should contact customer support for assistance by emailing- [email protected]

If you live in subzero conditions, the HomeBiogas system may not be suitable for you.

They are all written in the Booster Kit  manual, the most important ones are also printed on the cautions sticker on the side of the IP box.

1. This section contains important safety and operating instructions. Read and keep this user manual for future reference.

2. High Voltage! Do not touch wires while connected to the outlet – heating section included.

3. Do not use the Thermo-Regulator for any purpose other than its intended use.

4. Do not use the appliance in temperatures below -5°C/23°F. Do not store the appliance in temperatures below -20°C/-4°F.

5. Ensure the input voltage of your Thermo-Regulator model matches your local power supply.

6. Do not use the Thermo-Regulator if it has a damaged cord or plug, or if it is malfunctioning or damaged in any manner.

7. Do not pull on the cable to remove the plug from the socket – pull on the plug carefully to disconnect it.

8. Do not disassemble the product. Attempting to service the Thermo-Regulator by yourself may result in a risk of electrical shock or re.

9. Unplug the Thermo-Regulator from the electrical outlet when not in use or before any type of maintenance or cleaning.

10. A G.F.C.I (Ground fault circuit interrupter) & Residual Current Device (RCD) is mandatory.

11. Do not attempt to repair the Thermo-Regulator.

12. If you are unsure about your electrical infrastructure, consult a qualified electrician.

13. Ensure the conduit pipe is protected all along its routing.


Yes, the shield can be washed using regular soap and water. However, it’s important to avoid using abrasive cleaners or tools that could damage the surface.

Yes, he booster kit is customized for existing customers, with the exception for the ground insulation.

The HomeBiogas system can be activated in winter and you can expect to create flammable gas in 2 weeks.

The HomeBiogas experts set the temperatures for optimal working.  If you open the box, you are not under warranty anymore

Yes, the HomeBiogas system can be connected to a generator to generate electricity. However, only if the generators is accustomed for Biogas and the pressures we work with (around 5 millibars.)

Yes, but it’s important to ensure that the generator is properly sized and rated for the power requirements of the system.

The HomeBiogas Booster Kit is created specifically to control the temperature of the HomeBiogas system and to prevent overheating and ensure energy efficiency, and to withstand the harsh conditions of bio-digester environment, while other submersible heaters are not adapted for the HomeBiogas system.

The HomeBiogas system requires regular maintenance to ensure optimal performance and prevent damage or malfunction. This includes tasks such as cleaning the system, checking for leaks or damage, and replacing any worn or damaged components. If you need to replace a part, always consult with our customer support first ([email protected]). The manufacturer’s instructions should be followed for specific maintenance requirements and schedules.
